Thermo Scientific™ TraceGOLD™ GC Capillary Columns
Offering you a leap forward in GC capillary column performance delivering ultra low bleed, superior inertness and the highest levels of reproducibility guaranteed.
Product features:
Ultra low bleed – Leading to greater sensitivity, essential for GCMS applications, while providing extended column lifetime
High levels of reproducibility – Both run-to-run and column to column reproducibility. Expect every column to provide the same high levels of performance as the previous one
Superior inertness – Offering highly inert columns ensuring excellent peak shape and sensitivity, especially for highly active or difficult compounds
Wide range of stationary phases – Find a column suitable for your application
Filtered Search Results
Thermo Scientific™ TraceGOLD™ TG-5MS GC Columns
Employ the most widely used MS phase in gas chromatography with the 5% phenyl phase Thermo Scientific™ TraceGOLD™ TG-5MS GC Column.
Stationary Phase | TraceGOLD™ TG-5 MS |
---|---|
USP Type | G27, G36 |
Thermo Scientific™ TraceGOLD™ TG-624SilMS GC Columns, 1.4μm film thickness, 0.25mm I.D., 30m length
Optimize volatile organics analysis with this low-bleed, midpolarity GC column with high thermal stability.
Thermo Scientific™ TraceGOLD™ TG-624 and TG-624SilMS GC Columns
Optimize volatile organics analysis with this low-bleed, midpolarity GC column with high thermal stability.
Promotions are availablePolarity | Mid-Polar |
---|---|
USP Type | G43 |
Thermo Scientific™ TraceGOLD™ TG-WaxMS GC Columns
Analyze FAMEs with excellent thermal stability using this column.
Max. Temperature | 240/260°C |
---|---|
Stationary Phase | TraceGOLD™ TG-WAXMS |
Polarity | Polar |
USP Type | G14, G15, G16, G20, G39 |
Thermo Scientific™ TraceGOLD TG-5HT GC Columns
Thermo Scientific™ TraceGOLD TG-5HT GC Columns offer extended operation up to 400°C, ideal for high temperature GC applications.
Promotions are availableMax. Temperature | 380/400°C |
---|---|
Stationary Phase | TraceGOLD™ TG-5 HT |
Polarity | Low-Polar |
For Use With (Application) | Pesticides Analysis,GC/MS for Pesticides,GC/MS for Residual Solvents, Solvents, and Solvent Impurities |
USP Type | G27, G36 |
Product Line | TraceGOLD |
Thermo Scientific™ TraceGOLD™ TG-5MS Guard GC Columns with SafeGuard
Extend column lifetime and get more consistent results over a longer period of time.
Max. Temperature | 330/350°C (Standard Columns), 430°C (Metal Columns) |
---|---|
Stationary Phase | TraceGOLD™ TG-5 MS |
Polarity | Low-Polar |
Temperature Range | -60°C to +330/350°C |
For Use With (Application) | Active Compounds Analysis,GC/MS for Analysis of Active Compounds |
USP Type | G27, G36 |
Thermo Scientific™ TraceGOLD™ TG-5MT Metal GC Columns
Give greater stability and inertness at elevated temperatures and when working with highly active compounds with Thermo Scientific™ TraceGOLD™ TG-5MT Metal GC Columns.
Max. Temperature | 330/350°C (Standard Columns), 430°C (Metal Columns) |
---|---|
Stationary Phase | TraceGOLD™ TG-5 MT |
Polarity | Low-Polar |
USP Type | G27, G36 |
Thermo Scientific™ TraceGOLD TG-VRX GC Columns
Thermo Scientific™ TraceGOLD TG-VRX GC Columns provide good resolution and fast analysis times for volatile compounds.
Max. Temperature | 260°C |
---|---|
Stationary Phase | TraceGOLD™ TG-VRX |
Polarity | Non-Polar |
Thermo Scientific™ TraceGOLD TG-35MS GC Columns
Use these columns for a higher phenyl content that provides useful elution order and retention time changes.
Max. Temperature | 300/320°C |
---|---|
Stationary Phase | TraceGOLD™ TG-35 MS |
Polarity | Mid-Polar |
USP Type | G42 |
Thermo Scientific™ TraceGOLD TG-5SilMS GC Columns
Incorporates phenyl groups in the polymer backbone for improved thermal stability, reduced bleed and reduced susceptibility to oxidation.
Promotions are availableMax. Temperature | 330/350°C |
---|---|
Stationary Phase | TraceGOLD™ TG-5 SilMS |
Polarity | Low-Polar |
For Use With (Application) | GC/MS Applications Using Ion-Trap Systems,GC/MS for Polycyclic Aromatics, Phthalates, Phenols, Amines, and Organophosphates,GC/MS for Hydrocarbons Including Chlorinated Hydrocarbons |
USP Type | G27, G36 |
Thermo Scientific™ TraceGOLD™ TG-5SILMS Guard GC Columns with SafeGuard
The Thermo Scientific™ TraceGOLD™ TG-5SILMS Guard GC Columns with SafeGuard offer the benefit of an integrated SafeGuard for extended column lifetime.
Max. Temperature | 330/350°C |
---|---|
Stationary Phase | TraceGOLD™ TG-5 SILMS |
Polarity | Low-Polar |
For Use With (Application) | GC/MS Applications Using Ion-Trap Systems,GC/MS for Polycyclic Aromatics, Phthalates, Phenols, Amines, and Organophosphates,GC/MS for Hydrocarbons Including Chlorinated Hydrocarbons |
USP Type | G27, G36 |
Thermo Scientific™ TraceGOLD™ TG-OPP I and II GC Columns
Analyze organophosphorus pesticides with ultra-low bleed, superior inertness and consistent reproducibility.
Max. Temperature | 330°C |
---|---|
Length (Metric) | 30 m |
Polarity | Non-Polar |
For Use With (Application) | GC/MS for Organophosphorus Pesticides |
Thermo Scientific™ TraceGOLD TG-XLBMS GC Columns
Thermo Scientific™ TraceGOLD TG-XLBMS GC Columns offer a low polarity, low bleed column suitable for a wide range of applications.
Promotions are availableMax. Temperature | 340/360°C |
---|---|
Stationary Phase | TraceGOLD™ TG-XLBMS |
Polarity | Low-Polar |
Thermo Scientific™ TraceGOLD TG-1701MS GC Columns
Features a mix of cyano and phenyl groups for increased polarity and a different elution order relative to less polar columns.
Max. Temperature | 260/280°C |
---|---|
Stationary Phase | TraceGOLD™ TG-1701 MS |
Polarity | Mid-Polar |
USP Type | G46 |
Thermo Scientific™ TraceGOLD™ TG-17SilMS GC Columns
Optimize separation when analyzing active environmental compounds with this low-bleed GC column with superior inertness.
